CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–25
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Command or Query. (G.703 parameter)
Rx Ternary Code in the form x, where:
0=AMI
1=B8ZS
2=B6ZS
3=HDB3
Example: RTC=1 (selects B8ZS)
(see Description of
Arguments)
Command or Query. (IDR parameter)
Enable Receive backward alarm enable in the form xxxx, where:
0=Disable
1=External trigger Enable
(see Description of
Arguments)
Command or Query. (IDR parameter)
Sets or queries IDR ESC Type in the form x, where:
0=64k data channel
Command or Query. (D&I/D&I++ only)
(Note different format between command and query.)
Insert Timeslot in the form xxy, where:
xx = Channel 01 through 24
y = timeslot: 0-9, A=10, B=11, C=12, D=13,…V=31
yyyyyyyyyyy
indicating all 24 Insert
timeslots values
associated with the 24
Rx Satellite channels.
Forces the software to recenter the receive Plesiochronous/Doppler buffer.
Note: This command takes no arguments.
Example: RCB=
LNB Rx LO frequency information in the form xxxxxs, where:
xxxxx is the LO frequency: 03000 through 65000 MHz, or 00000=Off
s is the sign for the MIX (Note: negative mix induces a spectral inversion)
Note: For additional information refer to Chapter 5 for LO, MIX, and Spectrum Settings.
Terminal Frequency = RX LO
(see Description of
Arguments)
Rx Terminal Frequency, which is the frequency (MHz) being received from the satellite.
Note: For additional information refer to Chapter 5 for LO, MIX, and Spectrum Settings.
Resolution=100 Hz
Returns 00000.0000 if LNB LO is zero
Example: RTF=11650.2249 (MHz)
(see Description of
Arguments)
