CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–45
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Quad Drop &
Insert
QDI=
73 bytes
Command or Query.
Quad Drop & Insert Commands (E1 CCS Only)
QDI=pccddddddddddddddddddddddddddddddddCCssssssssssssssssssssssssssssssssrrrr, where:
p = Port number 1 thru 4
cc = Number of Drop Channels, 0-32.
Used to decide Port p’s TX Tributary Rate if Interface Type is Quad Drop & Insert (TFM=8).
d = 32 bytes defining Timeslot locations (or channels)
CC = Number of Insert Channels, 0-32.
Used to decide Port p’s RX Tributary Rate if Interface Type is Quad Drop & Insert (RFM=8).
s = 32 bytes defining Timeslot locations (or channels)
Timeslot definition:
0 = Unused
1-9 for timeslots 1–9,
A=10, B=11, C=12, D=13…V=31
z=timeslot zero
r = reserved (set to value 0)
Example 1:
131123456789ABCDEFGHIJKLMNOPQRSTUV031123456789ABCDEFGHIJKLMNOPQRSTUV00000
Port 1’s Drop channels 1–31 using timeslots 1–31. Same for Insert
Example 2:
30412340000000000000000000000000000204123400000000000000000000000000002000000
Port 3’s Drop channels 1–4 using timeslots 1–4. Same for Insert.
Note: This command is a bit forgiving in the sense that the modem accepts the command even though the
interface type is other than Quad Drop & Insert. This is intentional for use with the CRS-300 switch for 1:N
redundancy.
QDI=
QDI?
QDI*
QDI#
QDI?p
QDI?pn
(where n = 0 to 9
returns the QDI
portion of 1 of 10
stored
configurations for
a single port p)
QDI=pccddddddddd
dddddddddddddddd
dddddddCCssssssss
ssssssssssssssssss
ssssssrrrr
(Returns current
Quad D&I
configuration of a
single port p)
Configuration
Save
CST=
1 byte, value
of 0 thru 9
Command only.
Causes the modem to store the current modem configuration in Configuration Memory location in the form
x, where x=0 to 9.
Example: CST=4 (stores the current configuration in location 4)
CST=
CST?
CST*
CST#
N/A
N/A
Configuration
Load
CLD=
1 byte, value
of 0 thru 9
Command only.
Causes the modem to retrieve a previously stored modem configuration from Configuration Memory location in the
form x, where x=0 to 9
Example: CLD=4 (loads modem configuration from location 4 to be the active configuration)
CLD=
CLD?
CLD*
CLD#
N/A
N/A
