CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–49
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
…Equipment ID
(cont)
Q=IP-ACM symbol rate option, where
0=None
1=up to 300ksym/sec
2=up to 1200ksym/sec
3=up to 4100ksym/sec
R=Framing option
0=Standard: (Unframed, EDMAC, EDMAC2)
1 = Option 0 plus Open Network (IBS with hi-rate ESC, IDR, Audio)
S=D&I option
0=None
1=D&I,D&I++ for single port E1/T1
2=Option 1 plus Quad D&I (4 ports)
T= G.703 Clock Extension
0=Not installed, 1=installed on
U=Time based CnC option
0=Not installed
1=Fractional CnC installed
2=Time Limited CnC installed
3=Option 1 and Option 2
V=Header Compression
0=None
1=up to 5Mbps / 1200ksps (ACM)
2=up to 10Mbps / 4100ksps (ACM)
3=up to 15Mbps / 4100ksps (ACM)
4=up to 20Mbps / 4100ksps (ACM)
5=up to 25Mbps / 4100ksps (ACM)
W=Payload Compression
0=None
1=up to 5Mbps / 1200ksps (ACM)
2=up to 10Mbps / 4100ksps (ACM)
3=up to 15Mbps / 4100ksps (ACM)
4=up to 20Mbps / 4100ksps (ACM)
5=up to 25Mbps / 4100ksps (ACM)
X=Advanced QoS
0=Not installed, 1=Installed
Y=AES Encryption
0=Not installed
1=Installed
Z= Advanced Network Timing
0=Not installed
1=Installed
a= Carrier ID
0=Not installed
1=Installed
ssss = spares (0)
600/L Emulation: See CDM-600/600L manual
Example: EID=062510000000134473412113233000000 indicates all software options, TPC/LDPC card installed.
Note: To achieve LDPC or TPC to 25 Mbps, the modem will require:
• Hardware option B, slot 1, a TPC/LDPC Codec;
•
Software options: L: data rate FAST option to 25 Mbps AND M:TPC/LDPC data rate FAST option to 25 Mbps.
