CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–53
Parameter
Type
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
(Instruction &
Qualifier)
Response to
Query
4 = BUC no comms/bad checksum
5 = BUC PLL
6 = BUC temperature
h= LNB status/faults:
0 = OK, masked, or not present
1 = LNB current
2 = LNB voltage
When CnC is enabled and the modem is locked, ratio (in dB) is monitored between the interferer and the
desired power.
Example 1: CRM=+02 (interferer > desired) (format = sdd)
Example 2: CRM=LT11 (less than –11 dB)
Example 3: CRM=GT11 (greater than +11 dB)
Example 4: CRM=99.9 (not locked or CnC not enabled)
Example 5: CRM=AUTO (in CnC-APC mode)
(see Description of
Arguments)
When CnC is enabled and the modem is locked, delay (in microseconds) of the interferer is monitored.
Example 1: CDM=229500 (229.5 ms)
Example 2: CDM=999999 (not locked or CnC not enabled)
(see Description of
Arguments)
When CnC is enabled, an estimated frequency offset (in kHz) is calculated between the interferer and the
desired power.
Example 1: CFM=+001.0 (1 kHz)
Example 2: CFM=9999.9 (not locked or CnC not enabled)
(see Description of
Arguments)
When CnC is enabled and the modem is locked, ratio (in dB) between the interferer and the desired power
is monitored.. The precision is 0.1dB.
Example 1: CPR=+02.8 (interferer > desired) (format = sdd.d)
Example 2: CPR=LT11.0 (less than –11.0 dB)
Example 3: CPR=GT19.0 (greater than +19.0 dB)
Example 4: CPR=9999.9 (not locked or CnC not enabled)
Example 5: CPR=AUTO (in CnC-APC mode)
(see Description of
Arguments)
