CDM-625 Advanced Satellite Modem Revision 13
Appendix E MN-CDM625
E–39
Hot
Key
Dialog Window Option Entry
I Tx Backward Alarm Enable Port1
Typical for each entry – Use the ↑↓ arrow keys to select Off or On
J
Tx Backward Alarm Enable Port2
K Tx Backward Alarm Enable Port3
L
Tx Backward Alarm Enable Port4
M Rx Backward Alarm Enable Port1
N Rx Backward Alarm Enable Port2
O
Rx Backward Alarm Enable Port3
P Tx Backward Alarm Enable Port4
Q
AUPC Enable
Use the ↑↓ arrow keys to select Disable or Enable
R AUPC Remote Demod Target Eb No Enter a value from 0.0 to 14.9 dB
S
AUPC Tx Power Max Increase Enter a value from
0
to
9
dB
T AUPC Action On Max Power
Use the ↑↓ arrow keys to select No Action, Generate Tx Alarm
Max Power, or Generate Tx Alarm Minimum ModCod
U
AUPC Action On Remote Demod
Unlock
Use the ↑↓ arrow keys to select Go To Nominal Power, Go To
Max Power, or Hold
V
EDMAC Mode
Use the ↑↓ arrow keys to select Off, Master, or Slave
W EDMAC Address Enter a value from 0 to 9999
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
