CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–17
Selection
Setting
Fault-Logic:
Summary
or
No-Summary
. This controls whether or not an LNA Current-
Window fault activates the Summary Fault Relay, and further permits you to
select whether or not to switch the Online/Offline CSAT in the event of an LNA
Current-Window fault.
Press ENTER when done.
F.3.3.3.3.1.1.4 ODU: FSK-control  CSAT (2CSATs  CSAT #X) 
Configuration
 Misc
Misc: Cold-Start=Disabled AFR=Enable
Xref=No Ref-Adj=087 Sync-Clk=Y ()
Use the
◄ ►arrow keys to select the setting to edit, and then use the ▲▼ arrow keys to edit
that setting:
Selection
Setting
Cold-Start
If enabled, when the CSAT is powered on, the IF and RF outputs remain muted for 15
minutes.
AFR
(Auto Fault Recovery) This defines how a CSAT reacts to momentary fault conditions:
Off: CSAT mutes when faulted and remain muted.
On: CSAT mutes when faulted, but unmute after the fault goes away.
Xref
(External R eference) The C SAT aut omatically locks t o an e xternal 5 or 10 MHz
reference independent of the state of this selection. This selection determines whether
or not the Summary Fault Relay ac tivates i f t he CSAT loses lock w ith the ex ternal
reference.
Ref-Adj
Select a value for the Internal 10MHz Reference setting from
000
to
255
.
NOTE: The Internal Reference is set in the factory to be very accurate with the default
setting of 087. This setting is provided to compensate for the long-term frequency drift
of the oscillator.
Sync-Clk
(Default is NO.) Selecting YES and pr essing ENTER causes t he C SAT RTC ( Real-
Time Clock) to be synchronized to the Modem RTC.
Press ENTER when done.
