112 AV7000 LINEAR CAMERA
Far Distance Offset
Enter the S85 Far Distance Offset. This value is used when the S85 is unable to be set to the
correct distance due to some physical restriction. This value is added to the far of the S85 and
counterbalances the focusing information. This value is subtracted from the far distance of the
S85.
Trigger Source to S85
Enter the distance in inches from the trigger source to the S85.
Device is a Legacy S80
Click this check-box if your system uses the S80 Position Sensor(s).
Transmit Point Settings
Transmit Point Reference Edge
Select Leading Edge or Trailing Edge from the drop-down list to reference the leading or trailing
edge of the package.
Distance to Transmit Point
Enter a delay distance from the edge of trigger that the camera will wait until it transmits the
host message.
Transmit Point Advance
Enter the distance (amount of time) before (upstream) of the transmit point when the camera
will stop decoding the image data to allow time to get the host message ready to transmit. This
will help eliminate processing errors.
