118 AV7000 LINEAR CAMERA
Select No Position Sensor, Light Curtain, Dimensioner, S85, or S85 with Light Curtain from the
drop-down list, depending on the specific position sensor used by the system.
Position Sensor Height Offset
Enter the distance between the light curtain’s (light array’s) zero height reference point and the
conveyor’s surface. This should be set to zero (0) for other, non-light curtain position sensors.
Position Sensor Transmit Delay
Enter the distance from the position sensor to the transmit point in the field provided.
DL Light Curtain Settings
Connected to
Select a camera in the system to which the light curtain is connected.
Multicast LC Focus Data
Select Disable or Enable from drop-down. Enable if you have a Light Curtain and there are
multiple camera’s that should use the Light Curtain signal for focusing.
Dimensioner Settings
Serial Focus Connected to
Click the drop-down to select from the available devices to specify which device is receiving
the serial focus data.
Side by Side Verification
Select Enabled or Disabled from the drop-down list if your system requires Side by Side
Verification. This is only available for Dimensioners.
Dimensioner Results Tracking
Place Results from
Click the drop-down to select; Single DM System Connected, or the IP address of the
dimensioner results to use for Tracking.
Place Results Based on Tach
Select the check-box to enable placement of the Dimensioning results based on the
tachometer. This option works in conjunction with the DM3610 when the Datalogic Message is
selected as it's transmit message format. The camera will receive the message at the defined
Transmit Point Distance parameter.
See “Diagnostics | Message Placing Wizard” on page 317
Transmit Point Distance
Enter the distance in the field provided.This is the distance at which the camera is looking for
the information from the DM3610/DC3000 Transmit Point Reference Edge. This option is in
reference to the DM3610 message to the camera.
This option is different than the "Distance To Transmit Point" which is the point where the
camera transmits the host message
Transmit Point Reference Edge
Select Leading Edge or Trailing Edge from the drop-down list to reference the leading or trailing
edge of the package.This option is in reference to the DM3610 message to the camera.
It is different than the Transmit Point Reference Edge which is the which is the package edge
for the camera transmits the host.
S85 Configuration
Number of S85’s
Select none, 1, or potentially 2 depending on the number of S85's needed for the application.
The 1 or 2 options will not appear unless the S85 is connected to the camera.
S85#n Settings
Connected to
Select Not Assigned or a camera in the system to which the S85 is connected.
S85 Mounting Position
Select Top, Left or Right to specify the S85 position. This is in reference to the flow of product
through the system not which camera it will be providing the focus to.
Far Distance
Enter the S85 Far Distance. The Far Distance is the Far Working Distance of the camera that the
