OPERATING MODE
PRODUCT REFERENCE GUIDE
119
S85 is providing focus for. In most cases this is the far side of the conveyor, but there are some
applications where the far side of the conveyor and the far working distance of the camera can
be different.
Far Distance Offset
Enter the S85 Far Distance Offset. This value is used when the S85 is unable to be set to the
correct distance due to some restriction. This value is subtracted from the far Distance of the
S85 and compensates the focusing information.
Trigger Source to S85
Enter the distance from the trigger source to the light curtain.
Device is a Legacy S80
Click this check-box if your system uses the S80 Position Sensor(s)
Transmit Point Settings
Transmit Point Reference Edge
Select Leading Edge or Trailing Edge from the drop-down list to reference the leading or trailing
edge of the package.
Distance to Transmit Point
Enter the distance from the location of the trigger source to the host transmit point.
Transmit Point Advance
Enter the distance. This is the distance upstream of the transmit point when the camera will
stop decoding the image data. This will help eliminate processing errors.
Transmit Early If Decode Complete
Click the check box to transmit when decode is completed.
Transmit Early if New Trigger
Click the check box to transmit when new trigger is received. This will keep the camera from
misapplying the bar code data.
Green Spot Settings AV500 Only
Green Spot Mode
Select one of the following from the drop-down list:
•Disabled
Good Read - Immediate: this option will light the green LED at the time of the bar code
being decode. In an array only the camera that read the bar code will light
Good Read - Host Transmission: this option will light the green LED when the package
reaches the transmit point. In the on-line mode it will light when the trailing edge of the
package leaves the trigger photo sensor. In the Packtrack mode it will light when the defined
edge of the package, leading or trailing, arrives at the Distance To Transmit Point setting.
Green Spot On Time
Specify the amount of time is milliseconds that the Green Spot should remain on.
Redundant Controller Settings (Only appear if operating a Redundant System)
Controller Mode: Camera_1
Select one of the following from the drop-down list:
Auto-Detect: This option is used when multiple cameras and CBX’s are used and both can
be controllers. This is considered a redundant application. In this configuration there are two
camera's that will be connected to a CBX510. When Auto-Detect is selected the camera that
initializes first will become the DHCP controller and assume the 192.168.0.145 IP. The
Secondary Controller will assume the 192.168.0.146 IP. Both units can be DHCP Servers,
however the .145 will assume responsibility for providing all cameras a Sync IP address. The
secondary unit will assume .146 and the controller unit will see it as another camera.
Primary Controller: This option is used when the camera is in a redundant application. In
this configuration there are two camera's that will be connected to a CBX510. In this
configuration you will identify which of the two cameras will assume DHCP responsibility. The
secondary unit will not come into play until the primary unit fails.
Secondary Controller: This option is used when the camera is in a redundant application.
In this configuration there are two camera's that will be connected to a CBX510. When
Primary Controller is selected the camera selected as the Primary Controller will become the
DHCP controller and assume the 192.168.0.145 IP. The Secondary Controller will assume the
192.168.0.146 IP.
