Datalogic AV7000 User Manual

E-GENIUS
150 AV7000 LINEAR CAMERA
Enable 7DR Check Digit
Select the check box to enable 7DR Check Digit.
Transmit Start/Stop Char
Select the check box to allow Start/Stop Characters. This parameter is available only for
Codabar code symbologies.
Short Margin
Select the check box to enable. Available for Code 128, Code GS1-128, Interleaved 2 of 5, Code
39, Code GS1-128, EAN, UPC, CODABAR, and Code 39. This options allows the bar code to have
an illegal quiet zone on one side of the bar code. If selected this could increase the processing
time.
Code 93
Enable 7DR Check Digit
Select the check box to enable 7DR Check Digit.
Short Margin
Select the check box to enable. Available for Code 128, Code GS1-128, Interleaved 2 of 5, Code
39, Code GS1-128, EAN, UPC, CODABAR, and Code 39. This options allows the bar code to have
an illegal quiet zone on one side of the bar code. If selected this could increase the processing
time.
Data Matrix Options
Select the check box to enable the Data Matrix options available via the table shown below.
Data Matrix Fast Improve
Select the Data Matrix Fast Improve check box and the check box next to the Data Matrix type
codes required from the provided table. DataMatrix Fast Improve should only be used when
high quality Data Matrix symbols are present. Otherwise it will reduce performance.
NOTE: The 7DR Check Digit is not use with all code symbologies.
NOTE: For Codabar codes the start/stop characters must be considered in
the match conditions.
NOTE: The 7DR Check Digit is not use with all code symbologies.
