E-GENIUS
152
AV7000 LINEAR CAMERA
Postal Min/Max Bar Count:
Enter the minimum number of bars in the label. It is used for localization purposes (min bars)
and for final validation of the label (max bars).
QR Code
Code Module Size
Enter number of code modules in the field provided. Module size is expressed in micrometer
(500 micrometer = 0.5 mm)
GS1 DataBar
Type
Select Omnidirectional, Expanded, Limited, Expanded Stacked, or Stacked from the drop-down
list.
These options are available when reading GS1 DataBar stacked type barcodes, this parameter
can be enabled to apply a fixed safety margin to the decoding process in terms of decoding
time (number of scans). This parameter is particularly useful in applications that read tall
stacked type codes or on slow moving conveyors.
Maxicode
Maxicode Enable n
Select the check box corresponding to the Maxicode(s) to enable.
MaxiCode barcodes have different modes of operation. IDAutomation MaxiCode products
support the following modes:
• 2 = US Carrier with postal codes up to 9 digits in length. Approximately 93 characters may
be encoded in this mode.
• 3 = International Carrier with alpha-numeric postal codes up to 6 digits in length.
Approximately 93 characters may be encoded in this mode.
• 4 = Standard Symbol encodes general information for purposes other than the shipping
industry. Approximately 90 characters may be encoded in this mode.
• 5 = Secure Symbol encodes general information with more error correction. Approximately
74 characters may be encoded in this mode.
• 6 = Reader Program allows scanner manufacturers to program barcode readers.
UPS labels use Mode 2 or Mode 3 MaxiCodes.
