216 AV7000 LINEAR CAMERA
Server Settings FTP Server
FTP Server Type
Click to select SFTP or FTP from the drop-down.
IP Address
Enter the IP Address for the FTP Server.
Port Number
Enter the Port Number where you would like your images to go.
Use Global Username
Enter a Global username if applicable
Username
Enter a valid username.
Password
Click to “Enter Text with the Text Entry Tool” on page 92 and enter the password
required to access the server.
Passive Mode
Click the checkbox to enable Passive Mode.
File Transfer Timeout
Enter an amount of time in seconds within which the transfer of the image will timeout.
Destination Directory
Enter the complete path of the destination directory.
Server Settings External Viewer
Destination IP Address
Enter the IP Address of the External Viewer destination
Server Settings On Camera
Port Number
Port number of on Board FTP Server. Cannot be 22 which is SFTP Server.
Directory Splitting
Enable
Select the check box to enable directory splitting. Enabling this parameter causes the
destination directory to be split into subdirectories containing a number of images not greater
than the defined Split Destination Max File Number (see below). The subdirectories of the
Saving Path are numbered consecutively: 1, 2, 3, etc.
Max Number of Files per Directory
