88 Magellan™ 9300i / 9400i Scanners
Shift Test Metric (2 Kilogram Dual Interval ONLY)
The Shift Test checks to ensure that items placed anywhere on the weighing
surface of the scanner/scale are weighed properly. Refer to
Figure 48 when
performing this test.
Figure 48. Metric Shift Test
DUAL INTERVAL
1. Place and remove, in succession, a 2
kilogram load on the center of each of
the four quadrants: 2, 3, 4, and 5, and in
the center (1) of the scanner/scale’s
weighing platform (see
Figure 48). Verify
that the Remote Display shows a reading
of between 1.998 and 2.002 kg for each
quadrant/center test. Check that the dis
-
play returns to 0.000 between each load.
2. After verifying the accuracy of each
quadrant and the center of the weighing
surface, remove all weight from the
scale. This completes the Shift Test Met
-
ric (2 Kilogram).
(Models vary)
3
2
5
4
2
3
4
5
1
1

Datalogic Magellan 9300i Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Standard interfaces	RS-232
Connectivity technology	Wired
Product color	Black, Grey
Built-in display	No
Sustainability certificates	RoHS

Weight and Dimensions

Weight	- g
