Datalogic Magellan 9300i User Manual

Enter/Exit Programming Mode
Product Reference Guide 279
Global Mid-Label ID
This feature specifies a global mid-label ID that is added between two bar
codes for transmission.
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the Set Global Mid-Label ID on page 279 bar code below. You’ll need
to cover any unused bar codes on this and the facing page to ensure the
scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired mid-label ID characters; entered as two hex
pairs. A table containing the ASCII Character Set and their corresponding
Hex Values is available in the inside back cover of this manual. ASCII
parameters must be input by scanning a pair of hexadecimal digits for
each character. Thus, to set a two-character value of AB, bar codes con
-
taining the digits ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable
range for this option is any hex value from 00 to FF.
Complete the programming sequence by scanning the Enter/Exit Programming
Mode bar code.
Set Global Mid-Label ID
Default Label ID for this symbology is:
00 = No Global Mid-label ID
04C7(CR)
DEFAULT

Datalogic Magellan 9300i Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Standard interfaces	RS-232
Connectivity technology	Wired
Product color	Black, Grey
Built-in display	No
Sustainability certificates	RoHS

Weight and Dimensions

Weight	- g
