Datalogic Magellan 9300i User Manual

Enter/Exit Programming Mode General Scanner and Scale Features
164 Magellan™ 9300i / 9400i Scanners
Scale Enforced Zero Return
This feature sets the mode of enforcing the scale re-zeroing operation:
•Disable
• Non-zero for more than 4 minutes OR below zero
• Non-zero for more than 4 minutes OR below zero OR no zero between
weights
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan your selection from the bar codes below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan. The strategy is to select the
lowest possible filter level needed that allows normal scale operation.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
Scale Enforced Zero Return = Disable
Scale Enforced Zero Return = Non Zero for More Than 4 min-
utes OR Below Zero
Scale Enforced Zero Return = Non Zero for More Than 4 min-
utes OR Below Zero OR No Zero Between Weights
Scale Enforced Zero Return = Non Zero for 4 minutes
040800(CR)
040801(CR)
040802(CR)
040803(CR)
DEFAULT

Datalogic Magellan 9300i Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Standard interfaces	RS-232
Connectivity technology	Wired
Product color	Black, Grey
Built-in display	No
Sustainability certificates	RoHS

Weight and Dimensions

Weight	- g
