Enter/Exit Programming Mode
Product Reference Guide
269
Global Prefix/Suffix
Global Prefix
This feature applies to RS-232 interfaces (Standard, Wincor-Nixdorf, and Single
Cable). It specifies the prefix that is added to beginning of label transmission.
To specify the Global Prefix Character(s):
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code Set Global Prefix below. Cover any unused bar codes to
ensure the scanner reads only the bar code you intend to scan.
3. Scan the appropriate characters/digits from the Keypad on page 461 in
Appendix C that represent the hex designation for the desired charac-
ter(s). The ASCII Character Set and their corresponding Hex Values are
available in the inside back cover of this manual. ASCII parameters must be
input by scanning a pair of hexadecimal digits for each character. Thus, to
set a two-character value of AB, bar codes containing the digits ‘4’, ‘1’, ‘4’,
and ‘2’ must be scanned. The selectable range for this option is any hex
value from 00 to FF. Up to 20 hex pairs can be designated.
4. If designating the full 20 hex pairs, the scanner will exit Programming
Mode when the appropriate amount of digits have been scanned. If desig
-
nating less than 20 hex pairs, you can end the programming sequence
early by scanning the
Terminate Sequence on page 269 bar code.
5. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
NOTE
To specify “no Global Prefix,” scan 00.
Set Global Prefix
Terminate Sequence
Default setting for this feature is:
00 - No Global Prefix
DEFAULT
To Next Page
