Datalogic Magellan 9300i - Ttl

Enter/Exit Programming Mode Interface Related Features
230 Magellan™ 9300i / 9400i Scanners
RS-232 TTL
Specifies whether RS-232 interface provides TTL levels on the output pins TxD
and RTS.
Choices are:
• Normal RS-232 levels
• TTL levels
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code below which represents the desired setting for this fea-
ture. You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend to
scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
RS-232 TTL = Normal RS-232 levels
RS-232 TTL = TTL Levels
DEFAULT
028500(CR)
028501(CR)
