Enter/Exit Programming Mode
Product Reference Guide 381
I 2 of 5 Length 1
If I 2 of 5 Length Control is set to Fixed-Length decoding, this feature specifies
I 2 of 5 first fixed length. If I 2 of 5 Length Control is set to Variable-Length
decoding, this feature specifies the minimum label length.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the bar code, Set I 2 of 5 Length 1 on page 381 below. You’ll need to
cover any unused bar codes on this and the facing page to ensure that the
scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired label length. The selectable range for this
option is 02 to 50, even numbers only. Pad all single digit numbers with a
leading zero to yield a two-digit entry (02-50).
4. Complete the programming sequence by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
Set I 2 of 5 Length 1
Default setting for this feature = 06
0056(CR)
DEFAULT
