Product Reference Guide 495
Appendix G
Handheld Data Format Requirements
This appendix provides application notes to describe the general format of data
that can be accepted by the scanner through the auxiliary port as transmitted
from a handheld scanner.
Handheld Data Format Requirements General
RS232 - 9600 bps, 8 data bits, 1 stop bit, no parity.
RS-232 RTS is used to “bracket” the data received from the handheld: RTS
must be asserted high during data transmission, and de-asserted after
label transmission is complete.
No other flow control mechanisms are required or supported.
There must be a delay of at least 2 bit cell times (approximately 208
microseconds) following the transmission of the last character before de-
assertion of the RTS signal.
The de-assertion of the RTS signal must happen in less than 50 millisec-
onds after the last character is transmitted.
USB handhelds enumerate as a CDC ACM serial device.
USB devices should also bracket the data with the RTS equivalent.
The time between character transmission can be no longer than 50 milli-
seconds.
Symbologies requiring fixed lengths (UPC/EAN) will enforce length
requirements for validation of the label.
Handheld will be required to transmit start and stop characters for Cod-
abar and Code39 labels.
Appropriate industrial length requirements will be enforced (if configured)
for validation of the label.
Maximum label lengths will be enforced for label validation (i.e. labels lon-
ger than the maximum label size will not be validated).
Standard Datalogic formats generally use a single prefix character. see
specific formats section.
Maximum label size allowed including identifiers is 2714 bytes
Recommendations:
•Handheld should not be configured for audible label read indication.
•Handheld should not be configured for visual label read indication.
•Handheld should not be configured for continuous label read mode.
