90 Magellan™ 9300i / 9400i Scanners
Increasing- Load Test (Single Interval Phase 2/Dual Interval Phase 3)
Blanking Test
This test ensures that the scanner/scale will indicate its weighing capability has
been exceeded if a weight greater than 0.82 kilograms over its maximum upper
weight limit is placed upon the scale platter.
1. Place weights that total the upper limit plus 0.82 kilograms on the weigh
platter. For example: If the upper limit is set at 15 kilograms, place weight
totaling 15.82 kilograms.
2. Verify that the display shows a dash and three hyphens (_---). This is the
overweight
indication.
NOTE
The upper limit of the scale is configurable according to POS interface type and may
not necessarily be set at 15 kilograms, which is the standard setting. For this test,
continue to place weights in 2.50 kilograms increments only to the upper weight
limit set for your scale.
SINGLE INTERVAL DUAL INTERVAL
After completing the Shift Test, you must
complete the Increasing Load Test using
10.00, 12.50 and 15 kilograms of weight.
After completing the Shift Test, you must
complete the Increasing Load Test using
10.00, 12.50 and 15 kilograms of weight.
1. Place 10.00 kilograms in the center of
the weighing surface and check that the
display reads between 9.995 kg and
10.005 kg.
1. Place 10.00 kilograms in the center of the
weighing surface and check that the
Remote
Display reads between 9.995 kg and
10.005 kg.
2. Place an additional 2.50 kilograms in the
center of the weighing surface and
check that the display reads between
12.495 kg and 12.505kg.
2. Place an additional 2.50 kilograms in the
center of the weighing surface and check
that the display reads between 12.495 kg
and 12.505 kg.
3. Place an additional 2.50 kilograms in the
center of the weighing surface and
check that the display reads between
14.995 kg and 15.005 kg.
3. Place an additional 2.50 kilograms in the
center of the weighing surface and check
that the display reads between 14.995 kg
and 15.005 kg.
4. Remove the weights and verify that the
display reads 0.000 kg.
4. Remove the weights and verify that the
display reads 0.000 kg.
5. You have completed Phase 2 of the
increasing load test.
5. You have completed Phase 3 of the
Increasing Load Test.
NOTE
The scanner/scale may blank (show an underscore and three hyphens) at any weight
greater than its upper limit plus 0.82 kilograms are set upon the weighing surface.
