Programming Overview
Product Reference Guide
99
C. The programming sequence shown in example C requires scanning of a
single, extended length bar code. This special programming bar code con
-
tains all the data necessary to enter Programming Mode, set the Item Tag
1
and Item Value, and exit Programming Mode (all in one step).
Table 2. Programming Sequence
1. An “Item Tag” is a term used to describe an assigned number, which is encoded in a
programming bar code, that toggles (selects, enables, disables, etc.) a specific pro
-
gramming feature
1
1
C
A
B
23
123456
SET
Enter/Exit
Programming
Mode
Enter/Exit
Programming
Mode
Enter/Exit
Programming
Mode
Enter/Exit
Programming
Mode
ENABLE
NEW FEATURE
ENABLE NEW
FEATURE
USING THE
FOLLOWING
SETTINGS...
0
8
ITEM TAG ITEM VALUE END/RESET
0
ONE BAR CODE CONTAINS ENTER + ITEM TAG + ITEM VALUE + EXIT
