Enter/Exit Programming Mode Interface Related Features
206 Magellan™ 9300i / 9400i Scanners
Interface Type (continued)
To select the desired interface:
1. Disconnect current interface cable(s) if currently connected.
2. Scan the Enter/Exit Programming Mode bar code.
3. Scan the bar code representing the appropriate interface located on the
following pages. You’ll need to cover any unused bar codes adjacent to
and on any facing pages to ensure the scanner reads only the bar code you
intend to scan.
4. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
5. Connect new interface cable(s).
NOTE
Once the correct interface has been set, it will be necessary to
proceed to the appropriate pages in this manual that select
parameters and options for that interface. For example, if RS-
232 is selected, turn to the pages in this manual headed as
features specific to the RS-232 interface.

Datalogic Magellan 9300i Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Standard interfaces	RS-232
Connectivity technology	Wired
Product color	Black, Grey
Built-in display	No
Sustainability certificates	RoHS

Weight and Dimensions

Weight	- g
