24 Magellan™ 9300i / 9400i Scanners
Flange Mount vs. Shelf Mount
Flange mount scanners and scanner-scales are supported in the counter by
brackets built into the front and back of the scanner. The flange brackets rest in
a recessed pocket in the countertop and the scanner is suspended between
them.
Shelf mount scanners and scanner-scales are supported by means of a shelf
directly under the body of the scanner.
See the figure below for easy identification of flange and shelf mount scanners.
Figure 11. Flange Mount vs. Shelf Mount
Front and rear brackets
SHELF MOUNT
FLANGE MOUNT

Datalogic Magellan 9300i Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Standard interfaces	RS-232
Connectivity technology	Wired
Product color	Black, Grey
Built-in display	No
Sustainability certificates	RoHS

Weight and Dimensions

Weight	- g
