External Cable Pinouts
Product Reference Guide 459
Peripheral Ports / Connectors
REMOTE DISPLAY USB
POWER
CABLE
PIN Hardware: 4 pin SDL
Type B
a
a. The USB column in this table is for the type B connection only. The dual
stacked USB type A connections provide standard USB pinouts.
Hardware:
3 pin single row
1 +12 OUT +12 OUT VBUS Earth
2
LINE_A
DSPLY
Line A Display USB D- Signal GND
3
LINE_B
DSPLY
Line B Dis-
play
USBD+ 12V
4 GND Ground GND
