Datalogic Magellan 9300i

Product Reference Guide 479
RS-232 Ignore
Host Com-
mands on page
229
00 00 00 00 00 00 00 00
RS-232 TTL on
page 230
00
(normal)
00
(normal)
00
(normal)
00
(normal)
RS-232 TTL
Invert on page
231
00
(disable)
00
(disable)
00
(disable)
00
(disable)
RS-232 Beep on
ASCII BEL on
page 232
00
(disable)
00
(disable)
00
(disable)
00
(disable)
RS-232 Beep
After Weigh on
page 233
00
(disable)
00
(disable)
00
(disable)
00
(disable)
00
(disable)
Beep on Not on
File on page 234
01 (low vol) 01 (low vol) 01 (low vol) 01 (low vol) 01 (low vol) 01 (low vol) 01 (low vol)
RS-232 ACK
NAK Features
on page 235
00
(disable)
00
(disable)
00
(disable)
00
(disable)
RS-232 ACK
Character on
page 236
06 (ACK) 06 (ACK) 06 (ACK) 06 (ACK)
RS-232 NAK
Character on
page 237
15 (NAK) 15 (NAK) 15 (NAK) 15 (NAK)
RS-232 Retry on
ACK NAK Time-
out on page 238
01 (enable) 01 (enable) 01 (enable) 01 (enable)
RS-232 ACK
NAK Timeout
Value on page
239
01 (200ms) 01 (200ms) 01 (200ms) 01 (200ms)
RS-232 ACK
NAK Retry
Count on page
240
03
(3 retries)
03
(3 retries)
03
(3 retries)
03
(3 retries)
RS-232 ACK
NAK Error Han-
dling on page
241
00 (ignore) 00 (ignore) 00 (ignore) 00 (ignore)
Feature
Default
Master
RS-232
RS-232
Wincor-
Nixdorf
RS-232
Single
Cable
Keyboard
USB COM
/
USB TEC
USB OEM
IBM
Port 17
Port 9B
Port 5B
