Calibrating the Scale (Pounds & Kilograms)
Product Reference Guide 79
must be performed to assure that a scale will pass Weights and Measures
requirements before it is placed into commercial/retail service.
You have completed the scale calibration procedure. Before replacing the Cali-
bration Switch Cover and sealing the scale, you must now continue with the cal-
ibration verification tests to complete the scale’s calibration. If you are
weighing in pounds, continue with the following procedures to verify that the
scale was successfully calibrated and that it weighs properly. If you are weigh
-
ing in kilograms, turn to the instructions titled, "Calibration Verification (Kilo-
grams)" on page 86.
Figure 45. Calibration Cover and Switch Location
1
Calibration Seal Location
3
Calibration Switch Opening. Use a
long, blunt object to reach in and
press the Calibration Switch.
2
Calibration Access Cover
NOTE
If an EAS antenna is present, it must be lifted in order to access
the calibration switch. See
Figure 46.
3
1
2

Datalogic Magellan 9300i Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Standard interfaces	RS-232
Connectivity technology	Wired
Product color	Black, Grey
Built-in display	No
Sustainability certificates	RoHS

Weight and Dimensions

Weight	- g
