Symptom:
AIR OUT LET TEMP SENSO R SHO R T E D L OW (AC TI VE )
POSSIBLE CAUSES
AIR OUTLE T TE MPE RATURE SE NSOR
AIR OUTLE T TE MPE RATURE SE NSOR SIGNAL CIRCUIT SH ORTED TO GROUN D
AIR OUTLE T TE MPE RATURE SE NSOR SIGNAL CIRCUIT SH ORTED TO GROUN D CIRCUIT
AUTOMATIC TE MPE RATURE CONTROL (ATC)
AIR OUTLE T TE MPE RATURE SE NSOR SIGNAL CIRCUIT SH ORT TO SE NSOR GROU ND CIR-
CU IT
TE S T ACTION AP PLICAB ILITY
1 Tur n th e ign it ion off.
Discon n ect t he Air Ou t let Temper a t u r e Sen sor h a r n ess con n ect or.
Tur n th e ign it ion on .
Wit h th e DRBIII", r ecor d a nd er a se Au t om a t ic Tem per a t u r e Con t r ol DTCs.
Tur n th e ign it ion off, wa it 5 seconds, th en t u r n th e ign it ion on .
Wit h th e DRBIII", r ea d t he Aut om a t ic Tem pera t u r e Con t r ol DTCs.
Does t h e DRBIII" displa y: AIR OUTLE T TE MP SE NSOR HIGH OR OP E N?
All
Ye s → Repla ce t he Air Ou t let Tem per a t u r e Sen sor in a ccor da n ce wit h
th e Ser vice In form a t ion .
Per for m BODY VERIFICATION TE ST - VE R 1.
No → Go To 2
2 Tur n th e ign it ion off.
Discon n ect t he Aut om a t ic Tem pera t u r e Con t r ol (ATC) C1 ha r n ess conn ect or.
Mea su r e t h e r esist a n ce bet ween gr oun d an d t h e Air Ou t let Tem per a t u r e Sen sor
Sign al cir cu it.
Is t h e resista n ce below 10k ohm s?
All
Ye s → Repa ir t h e Air Ou t let Temper a t u r e Sen sor Sign a l cir cu it for a
sh or t to gr oun d.
Per for m BODY VERIFICATION TE ST - VE R 1.
No → Go To 3
3 Tur n th e ign it ion off.
Discon n ect t he Aut om a t ic Tem pera t u r e Con t r ol (ATC) C1 ha r n ess conn ect or.
Mea su r e th e r esist a n ce bet ween t h e Air Ou t let Tem per a t u r e Sen sor Sign a l cir cu it
an d t h e Gr ou n d cir cu it.
Is t h e resista n ce below 10k ohm s?
All
Ye s → Repa ir t h e Air Ou t let Temper a t u r e Sen sor Sign a l cir cu it for a
sh or t to th e Gr ou n d cir cu it.
Per for m BODY VERIFICATION TE ST - VE R 1.
No → Go To 4
136
HEAT IN G & A/C
