NOTE: If the retaining lock is installed, remove it,
rotate engine and install lock once again.
(2) Carr y out test of other cylin ders in the firin g
order of engine.
CY LI N DER LEAK DOWN VALU ES
CYLINDER LEAK
DOWN PERMISSIBLE
TOTAL LOSS
± 25%
CYLINDER LEAK
DOWN PERMISSIBLE
LOSS AT VALVES AND
CYLINDER HEAD
± 10%
CYLINDER LEAK
DOWN PERMISSIBLE
LOSS AT PISTON AND
RINGS
± 20%
STANDARD PROCEDURE - DETERMINING CYL-
INDER PRESSURE LOSS
If an increa sed pr essu re loss was found with the
cylinder lea k test, inspect the engine by listening a t
the cylinder head gasket, a ir inta ke area, exhau st , oil
fill opening an d where inject ors and glow plugs enter
the cylinder h ead. Also check the engine coolan t in
the ra diat or or expansion reservoir for th e formation
of bubbles.
Possible causes for the pressur e loss ar e:
POSSI BLE CAU SE FOR PRESSU RE LOSS
CONDITION POSSIBLE
CAUSES
CORRECTION
AIR LOSS
THROUGH
GLOW PLUG,
INJECTOR, AD-
JACENT CYL-
INDERS, OR
AIR BUBBLES
IN COOLANT
1. Sealing Sur-
faces
Repair Sealing
Surfaces
2. Gaskets 2. Replace
Component or
Gasket
3. Cylinder
Head Gasket
3. Replace Cyl-
inder Head
Gasket
AIR LOSS
THROUGH AIR
INTAKE AREA
1. Sealing Sur-
faces
1. Remove Cyl-
inder Head for
Further Inspec-
tion
CONDITION POSSIBLE
CAUSES
CORRECTION
2. Intake
Valves and
Seats
2. Replace
Valves, Guides
or Seats
AIR LOSS
THROUGH EX-
HAUST
Sealing Surfac-
es
Remove Cylin-
der Head for
Further Inspec-
tion
2. Exhaust
Valves and
Seats
2. Replace
Valves, Guides
or Seats
AIR LOSS
THROUGH OIL
FILL OPENING
1. Sealing Sur-
faces
Remove Engine
for Further In-
spection
2. Pistons, Pis-
ton Rings
2. Replace Pis-
tons or Piston
Rings
It is possible to pin poin t the pressur e loss of the
relevan t cylin der by spra yin g with clean engine oil.
Engine oil sea ls off the ga p bet ween the pist on and
cylinder wall briefly. If a reduced pr essu re loss now
occurs for a sh ort t ime, the ca use is very likely to be
the pist ons, piston rings or cylinder contact sur faces
of the relevant cylinder.
Deter mining the cause can be falsified by the posi-
tion of the piston ring joints. If suspicion exists t hat
the loss of pressure is ca used by the piston ring
joints being position ed direct ly one above t he other,
fit the parts to the engine and repeat this test after
running the engine for a sh ort tim e.
REM OVAL
REMOVAL - ENGINE COVER
(1) Remove th e ret aining screws a nd remove cover
(Fig. 2).
9 - 4 ENGINE VA
