CONNECTOR NAME/NUMBER COLOR LOCATION FIG.
Wiper On/Off Relay (Fuse Block No. 1) In Fuse Block No.1 N/S
Wiper/Turn Signal/Engine Start Control Mod-
ule (In Fuse Block 1)
In Fuse Block No.1 N/S
GROU N DS
GROUND NUMBER LOCATION FIG.
G100 Underhood-Left Front 52
G101 Underhood-Right Front 52
G102 Underhood-Right Front 52
G200 Engine Compartment-Left 8,10, 52
G201 Under Driver Seat 52
G202 Under Driver Seat 36, 52
G203 Dash 19, 52
G300 Right Rear-Body 52
G301 Right Rear-Body Top 52
G302 Engine Compartment-Left Front 52
G303 Left Front Instrument Panel 5
G304 Front Center Headliner 5
SPLI CES
SPLICE NUMBER LOCATION FIG.
S100 Under Drivers Seat 18
S101 Instrument Panel 18
S102 Under Drivers Seat 18
S103 Under Drivers Seat 18
S104 Near Headlamp Assembly-Left 27
S105 Engine Compartment-Left 7
S106 Near Wheel 48
S108 Instrument Panel 18
S175 Engine Compartment-Left 18
S176 Engine Compartment-Left 18
S177 Engine Compartment-Left 18
S178 Engine Compartment-Left 18
S180 Left Plenum 27
S200 Engine Compartment-Left 1, 9
S201 Instrument Panel 21
S202 Instrument Panel 21
S203 Instrument Panel 18
S204 Near Brake Lamp Switch 18
S205 Instrument Panel 18
S206 Instrument Panel 18
S207 Near Time Delay Relay 18
S208 Near Time Delay Relay 18
8W - 91 - 10 8W-91 CONNECTOR/GROUND/SPLICE LOCATION VA
