Symptom List:
1-2/4-5 S OLEN OID CIRCU IT
1-2/4-5 S OLEN OID CIRCU IT SHORT TO GROU N D
Te s t N o t e : Al l s y m p t o m s l i s t e d a b o v e a r e d i a g n o s e d u s i n g t h e s a m e t e s t s .
Th e title fo r th e te s ts w ill be 1-2/4-5 SOLEN OID CIRCU IT.
Wh e n Mo n i to re d a n d S e t Co n d it i o n :
1-2/4-5 S OLENOID CIRCU IT
Wh en Mon it or ed: Alwa ys m on it or ed wit h syst em a ct ive a t ea ch ign ition cycle.
Set Con dit ion : If t h e TCM det ect s a sh or t t o gr oun d or ba t ter y on t he solen oid con tr ol
cir cuit , sh or t ed solen oid, open solen oid, or a n open or sh or ted solen oid con t rol circu it dr iver
in the TC M.
1-2/4-5 S OLENOID CIRCU IT SHOR T TO GROU N D
Wh en Mon it or ed: Alwa ys m on it or ed wit h syst em a ct ive a t ea ch ign ition cycle.
Set Con dit ion : If t h e TCM det ect s a sh or t t o gr oun d or ba t ter y on t he solen oid con tr ol
cir cuit , sh or t ed solen oid, open solen oid, or a n open or sh or ted solen oid con t rol circu it dr iver
in the TC M.
POSSIBLE CAUSES
IN TE RMITTE NT WIRING AND CONNECTORS
1-2/4-5 SOLE NOID CONTROL CIRCUIT OP E N
1-2/4-5 SOLE NOID CONTROL CIRCUIT SH ORT TO GROU ND
1-2/4-5 SOLE NOID CONTROL CIRCUIT SH ORT TO OTH ER CIRCUITS
1-2/4-5 SOLE NOID
TCM - 1-2/4-5 SOLE NOID CIRCUIT
24
TRANSMISSION - NAG1
