TE S T ACTION AP PLICAB ILITY
2 Wit h th e DRBIII#, r ea d Tra n sm ission DTCs.
NOTE: If the DTC, CAN BUS CIRCUIT, is present, perform diagnostics on
that symptom first.
Is t h e DTC, CAN BUS CIRCU IT, pr esen t ?
All
Ye s → Refer t o t h e Tra n sm ission cat egor y an d per for m th e a ppr opr ia te
sym pt om .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 3
3 Wit h th e DRBIII#, r ea d Tra n sm ission DTCs.
Is t h e DTC Accel Peda l Sen sor CAN Messa ge In cor r ect displa yed a s ACTIVE ?
All
Ye s → Go To 4
No → Go To 8
4 Ign ition on, en gine n ot ru n n in g.
Wit h th e DRBIII#,readEngineDTCs.
Are t h ere a n y E n gin e bu s r ela t ed DTCs pr esen t ?
All
Ye s → Refer t o t h e Comm u n ica t ion cat egor y an d per for m th e a ppr opr i-
at e sympt om .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 5
5 Ign ition on, en gine n ot ru n n in g.
Wit h th e DRBIII#,readEngineDTCs.
Are t h ere a n y Accel P eda l DTCs pr esen t ?
All
Ye s → Refer t o t h e Dr ivea bilit y ca t egor y a n d per form t h e appr opr ia t e
sym pt om .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 6
6 Repla ce th e Tra n sm ission Con t r ol Modu le.
NOTE: Perform the transmission verification test.
Did t h e DTC "Accel P eda l Sen sor CAN Messa ge In cor r ect " reset?
All
Ye s → Go To 7
No → Test Com plet e.
7 If t h er e ar e no possible cau ses r em a in ing, view repa ir. All
Repa ir
Repla ce th e E n gin e Con t r ol Modu le.
Per for m NAG1 TRANSMISSION VERIF ICATION TEST - VER 1.
8 Th e con dit ion s necessar y to set th is DTC a re n ot pr esen t a t th is t ime.
Usin g th e sch em a t ics as a gu ide, inspect t h e wirin g an d conn ect or s specific t o t his
cir cu it .
Wiggle th e wir es wh ile ch eck in g for sh or t s a n d open cir cu it s.
NOTE: Ch e c k fo r a n y Te ch n ic a l S e rv ic e B u lle t in s th at m a y ap p ly.
Wer e th er e an y pr oblem s fou n d?
All
Ye s → Repa ir a s n ecessa ry
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Test Com plet e.
47
TRANSMISSION - NAG1
ACC E L P EDAL SE NSO R C AN ME SSAG E I NC ORREC T — Co n t in ued
