Dodge Sprinter 2006 - Page 2232

Symptom:
IC/ATC CAN MES S AGE MIS SIN G
POSSIBLE CAUSES
CAN BU S CIRCUIT DTC PRE SE N T
AUTOMATIC TE MP CONTROL DTCS P RE SE NT
INSTRUMENT CLUSTER DTCS PRESE NT
OP E N CAN BUS CIRCUITS AT IN STRU ME N T CLUSTE R
OP E N CAN BUS CIRCUITS AUTOMATIC TE MP CONTROL
AUTOMATIC TE MP CONTROL
INSTRUMENT CLUSTER
TE S T ACTION AP PLICAB ILITY
1 NOTE: Low fluid level can be the cause of many transmission problems. If
the fluid level is low locate and repair the leak then check and adjust the
flui d lev el p er t h e s e r vi c e i n fo r m a ti o n .
NOTE: Always perform diagnostics with a fully charged battery to avoid
fa ls e s y m p t o m s .
Wit h t h e DRBIII#, r ea d t h e en gin e DTCs. Ch eck a n d r epa ir all en gin e DTCs pr ior to
per for m in g t r a n sm ission sympt om dia gnost ics.
Wit h th e DRBIII#, r ea d a n d recor d a ll Tra n sm ission DTCs.
NOTE: Ch e c k c o n n e c to rs - Cle a n /re pa i r a s n e c e s s a ry. P o o r p in to te rm in a l
connections can set DTCs.
Usin g t h e wir in g dia gr a m /schem a t ic a s a gu ide, in spect t he wir in g a n d con n ect or s.
Repa ir a s n ecessa r y.
Most DTCs set on st a r t up bu t som e m u st be set by dr iving th e veh icle su ch t h a t a ll
dia gnost ic m on itor s h a ve r u n .
Note: Verify flash level of transmission controller. Some problems are
corrected by software upgrades to the transmission controller.
NOTE: Ch e c k fo r a n y Te ch n ic a l S e rv ic e B u lle t in s th at m a y ap p ly.
Per for m t h is pr ocedu r e pr ior to Sym pt om dia gn osis.
All
Con t in u e
Go To 2
2 Ign ition on, en gine n ot ru n n in g.
Wit h th e DRBIII#, r ea d Tra n sm ission DTCs.
NOTE: If the DTC, CAN BUS CIRCUIT, is present, perform diagnostics on
that symptom first.
Is t h e DTC, CAN BUS CIRCU IT, pr esen t ?
All
Ye s → Refer t o t h e Tra n sm ission cat egor y an d per for m th e a ppr opr ia te
sym pt om .
No → Go To 3
3 NOTE:NOTE:If vehicle is equipped with Air Conditioning diagnose the ATC
system first.
Is t h e veh icle equ ipped wit h air con dit ion in g?
All
Ye s → Go To 4
No → Go To 6
72
TRANSMISSION - NAG1
