TE S T ACTION AP PLICAB ILITY
2 Ign ition on, en gine n ot ru n n in g.
Wit h th e DRBIII#,eraseDTCs.
Wit h th e DRBIII#, per for m t h e Solen oid Test
Wit h th e DRBIII#,readDTCs.
Did t h e DTC, Mod P r ess SOLE NOID CIRCU IT, r eset ?
All
Ye s → Go To 3
No → Go To 7
3 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Con t r ol Module C2 ha r n ess conn ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e th e r esist a n ce of t h e Mod. P r ess Solen oid Con t r ol circu it fr om th e TCM C2
ha r n ess con n ect or t o t h e Tra n sm ission Solen oid Assembly h a r n ess con n ect or.
Is t h e resista n ce a bove 5.0 ohm s?
All
Ye s → Repa ir t h e Mod. P r ess Solen oid Con t r ol cir cu it for a n open .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 4
4 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Con t r ol Module C2 ha r n ess conn ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e th e resist a n ce bet ween gr ou n d a n d t h e Mod. P r ess Solen oid Con t r ol cir cu it .
Is t h e resista n ce below 5.0 ohm s?
All
Ye s → Repa ir t h e Mod. P ress Solen oid Con t r ol cir cu it for a sh or t t o
gr ou n d.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 5
5 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Con t r ol Module C2 ha r n ess conn ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e th e r esista n ce of t he Mod Pr ess Solen oid Con t r ol circu it t o a ll oth er circu it s
in th e Tra n sm ission Solen oid Assembly h a r n ess con n ect or.
Is t h e resista n ce below 5.0 ohm s bet ween an y oth er cir cuit ?
All
Ye s → Repa ir t h e Mod. P ress Solen oid Con t r ol cir cu it for a sh or t t o ot her
cir cu it s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 6
85
TRANSMISSION - NAG1
MODUL ATI NG P RESSURE SO LENO ID C IRC UI T — Co nt in ued
