TE S T ACTION AP PLICAB ILITY
5 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e th e r esist a n ce of t h e Sen sor Gr ou n d cir cu it from th e TCM C2 h a r n ess
conn ect or t o t h e Tra n sm ission Solen oid Assem bly h a r n ess con nect or.
Is t h e resista n ce a bove 5.0 ohm s?
All
Ye s → Repa ir t h e Sen sor Gr ou n d cir cu it for an open .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 6
6 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e t he r esist a nce of th e N 3 Speed Sen sor Sign a l circu it t o all oth er cir cu it s in
th e Tra n sm ission Solen oid h a r n ess con n ect or.
Is t h e resista n ce below 5.0 ohm s bet ween an y oth er cir cuit ?
All
Ye s → Repa ir t h e N3 Speed Sen sor Sign a l cir cu it for a sh or t t o oth er
cir cu it -s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 7
7 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e t h e r esist a n ce bet ween grou n d a n d th e N3 In pu t Speed Sen sor Sign a l
cir cu it .
Is t h e resista n ce Below 5.0 ohm s?
All
Ye s → Repa ir t h e N3 In pu t Speed Sen sor Sign al cir cu it for a sh or t t o
gr ou n d.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 8
8 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e t h e resist a n ce of t he Sen sor Gr oun d cir cu it t o a ll ot h er cir cu it s in t h e
Tra n sm ission Solen oid h a r ness con n ect or.
Is t h e resista n ce below 5.0 ohm s bet ween an y oth er cir cuit ?
All
Ye s → Repa ir t h e Sen sor Gr ou n d cir cu it for a sh or t t o ot h er circu it s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 9
93
TRANSMISSION - NAG1
N3 INPUT SPEED SENSOR CIRCUIT — Co n t inued
