Dodge Sprinter 2006 - Page 2260

TE S T ACTION AP PLICAB ILITY
2 Ign ition on, en gine n ot ru n n in g.
Wit h th e DRBIII#,eraseDTCs.
Wit h th e DRBIII#, per for m t h e Solen oid Test .
Wit h th e DRBIII#,readDTCs.
Did t h e DTC, SH IF T P RE S SU RE SOLE N OID CI RCUI T, r eset ?
All
Ye s → Go To 3
No → Go To 7
3 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Con t r ol Module C2 ha r n ess conn ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e th e r esist a n ce of th e Sh ift P r essu r e Solen oid Con t r ol cir cu it fr om t h e TCM
C2 h a r ness con n ect or to t h e Tra n sm ission Solen oid Assembly h a r n ess con n ect or.
Is t h e resista n ce a bove 5.0 ohm s?
All
Ye s → Repa ir t h e Sh ift P r essu r e Solen oid Con t r ol cir cuit for an open .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 4
4 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Con t r ol Module C2 ha r n ess conn ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e t h e r esist a n ce bet ween grou n d a n d t h e Sh ift Pr essu r e Solen oid Con t r ol
cir cu it .
Is t h e resista n ce below 5.0 ohm s?
All
Ye s → Repa ir th e Sh ift P r essu r e Solen oid Con t r ol cir cu it for a sh or t t o
gr ou n d.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 5
5 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Con t r ol Module C2 ha r n ess conn ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
No t e : Ch e c k co n n e ct o rs - Cle a n /re pa ir a s n e c e s s a ry.
Mea su r e th e r esist a n ce of t h e Sh ift P r essu r e Solen oid Con t rol cir cu it t o all oth er
cir cu it s in t he Tra n sm ission Solen oid h a r n ess con n ect or.
Is t h e resista n ce below 5.0 ohm s bet ween an y oth er cir cuit ?
All
Ye s → Repa ir th e Sh ift P r essu r e Solen oid Con t r ol cir cu it for a sh or t t o
oth er cir cu it s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 6
100
TRANSMISSION - NAG1
SHIFT PRESSURE SOLENOID CIRCUIT — Co nt inued
