Symptom:
SLA CAN MESSAGE INCORRECT
POSSIBLE CAUSES
SH IF T LEVE R ASSE MBLY DTCS P RE SE NT
PCM/E CM - EN GINE TORQUE MESSAGE INCORRE CT
TCM - TORQUE ME SSAGE INCORRECT
TE S T ACTION AP PLICAB ILITY
1 NOTE: Low fluid level can be the cause of many transmission problems. If
the fluid level is low locate and repair the leak then check and adjust the
flui d lev el p er t h e s e r vi c e i n fo r m a ti o n .
NOTE: Always perform diagnostics with a fully charged battery to avoid
fa ls e s y m p t o m s .
Wit h t h e DRBIII#, r ea d t h e en gin e DTCs. Ch eck a n d r epa ir all en gin e DTCs pr ior to
per for m in g t r a n sm ission sympt om dia gnost ics.
Wit h th e DRBIII#, r ea d a n d recor d a ll Tra n sm ission DTCs.
NOTE: Ch e c k c o n n e c to rs - Cle a n /re pa i r a s n e c e s s a ry. P o o r p in to te rm in a l
connections can set DTCs.
Usin g t h e wir in g dia gr a m /schem a t ic a s a gu ide, in spect t he wir in g a n d con n ect or s.
Repa ir a s n ecessa r y.
Most DTCs set on st a r t up bu t som e m u st be set by dr iving th e veh icle su ch t h a t a ll
dia gnost ic m on itor s h a ve r u n .
Note: Verify flash level of transmission controller. Some problems are
corrected by software upgrades to the transmission controller.
NOTE: Ch e c k fo r a n y Te ch n ic a l S e rv ic e B u lle t in s th at m a y ap p ly.
Per for m t h is pr ocedu r e pr ior to Sym pt om dia gn osis.
All
Con t in u e
Go To 2
2 Ign ition on, en gine n ot ru n n in g.
Wit h th e DRBIII#,readEngineDTCs.
Are t h ere a n y per for m a n ce or bu s r ela t ed E n gin e DTCs pr esen t ?
All
Ye s → Refer to t h e Sh ift Lever cat egor y a n d per for m th e a ppropr ia t e
sym pt om .
No → Go To 3
3 Repla ce an d pr ogr a m th e E CM per th e Ser vice In form a t ion.
Wit h th e DRBIII#, er a se Tra n sm ission DTCs.
Dr ive th e veh icle per for m in g m u lt iple a ggr essive upsh ift s a n d downsh ift s.
Wit h th e DRBIII#, r ea d Tra n sm ission DTCs.
Did t h e DTC, E NGINE TORQUE ME SSAGE IN CORRE CT, r eset?
All
Ye s → Go To 4
No → Test Com plet e
Per for m N AG1 TRANSMISSION VERIF ICATION TE ST - VE R 1.
4 If t h er e ar e no possible cau ses r em a in ing, view repa ir. All
Repa ir
Repla ce th e Tra n sm ission Con t r ol Modu le.
Per for m NAG1 TRANSMISSION VERIF ICATION TEST - VER 1.
102
TRANSMISSION - NAG1
