TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off t o t h e lock posit ion .
Rem ove t h e TCM h a r n ess con nect or.
Discon n ect t he Solen oid h a r ness con n ect or.
Ch eck th e resist a n ce bet ween t h e Solen oid Su pply cir cu it a nd a ll ot h er cir cu it s in t h e
TCM h a rn ess con n ect or.
Is t h e resista n ce below 5.0 ohm s bet ween Solen oid Su pply an d a n y ot h er cir cuit ?
All
Ye s → Repa ir t h e Solen oid Su pply cir cu it sh ort t o ot h er cir cu it s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Th e TCM h a s an in ter n a l er r or. Repla ce t h e Tra nsm ission Con t r ol
Modu le.
Per for m N AG1 TRANSMISSION VERIF ICATION TE ST - VE R 1.
106
TRANSMISSION - NAG1
SOLEN OID SU P P LY/WATCHDOG — Co n t i n u ed
