TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C1 ha r n ess con n ect or.
Star t t he engine.
In cr ea se t h e En gin e Speed t o 1500 RP M.
Mea su r e t h e volt a ge of t h e Tr a n sm ission Rela y Ou t pu t cir cu it in t h e TCM C1
ha r n ess con n ect or.
Is t h e volt a ge below 9.0 volt s?
All
Ye s → Repa ir th e Tra n sm ission Rela y Ou t pu t cir cu it for a n open or high
resist a n ce.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Repla ce th e Tra n sm ission Con t rol Modu le.
Per for m N AG1 TRANSMISSION VERIF ICATION TE ST - VE R 1.
110
TRANSMISSION - NAG1
SYS TEM U ND ERVOLTAGE — Co nt in ued
