TE S T ACTION AP PLICAB ILITY
2 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
Star t t he engine.
Wit h th e br a kes fir m ly a pplied, sh ift th e gea r select or in t o Dr ive.
Did t h e en gin e st a ll or st u m ble?
All
Ye s → Repa ir t h e in t er n al tr a n sm ission . P a y pa r t icu la r a t t en t ion t o th e
compon en t s r ela t ed to th e TCC. Refer t o th e Ser vice In for m a t ion
for th e pr oper r epa ir pr ocedu r e.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 3
3 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
Mea su r e th e resista n ce between gr ou n d a n d t h e TCC Solen oid Cont r ol cir cu it .
Is t h e resista n ce below 5.0 ohm s?
All
Ye s → Repa ir t h e TCC Solen oid Cont r ol cir cu it for a sh or t to gr ou n d.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 4
4 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid h a r n ess con n ect or.
Mea su r e th e resist a n ce of th e TCC Solen oid Con t r ol cir cu it t o a ll ot h er cir cu it s in t h e
Tra n sm ission Solen oid h a r ness con n ect or.
Is t h e resista n ce below 5.0 ohm s on a n y cir cu it ?
All
Ye s → Repa ir t h e TCC Solen oid Con t r ol circu it for a sh or t t o ot h er
cir cu it s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Repla ce th e Tra n sm ission Con t rol Modu le.
Per for m N AG1 TRANSMISSION VERIF ICATION TE ST - VE R 1.
116
TRANSMISSION - NAG1
TCC S TU CK ON — Co n t i n u ed
