TE S T ACTION AP PLICAB ILITY
2 Ch eck th e Sh ift er Assem bly a dju st m en t per t h e Service In for m a t ion .
Wa s t h e Sh ift er Assem bly a dju st ed cor r ect ly?
All
Ye s → Go To 3
No → Adj u st th e Sh ifter Assem bly per th e Ser vice In for m a t ion .
Per for m N AG1 TRANSMISSION VERIF ICATION TE ST - VE R 1.
3 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
Mea su r e th e r esist a n ce of th e Sen sor Gr ou n d cir cu it bet ween t h e TCM C2 h a r n ess
conn ect or a n d t he Tra n sm ission Solen oid Assem bly h a r n ess con n ect or.
Is t h e resista n ce a bove 5.0 ohm s?
All
Ye s → Repa ir th e Sen sor Gr ou n d cir cu it for a n open or h igh resist a n ce.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 4
4 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
Mea su r e t he r esist a nce of t he Tr a n sm ission Tem p Sen sor - P/N Swit ch cir cu it
bet ween t h e TCM C2 h a r n ess con n ect or a n d t h e Tr a n smission Solen oid Assem bly
ha r n ess con n ect or.
Is t h e resista n ce a bove 5.0 ohm s.
All
Ye s → Repa ir t h e Tr a n sm ission Temp Sen sor - P/N Swit ch cir cu it for a n
open .
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 5
5 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
Mea su r e th e r esist a n ce bet ween gr ou n d a n d th e Tr a n sm ission Tem p Sen sor - P/N
Swit ch cir cu it .
Is t h e resista n ce below 5.0 ohm s?
All
Ye s → Repa ir t h e Tr a n sm ission Tem p Sen sor - P /N Swit ch circu it for a
sh or t to gr oun d.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 6
6 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C1 an d C2 ha r n ess con nect or s.
Discon n ect t he Tr an sm ission Solen oid Assem bly h a r n ess con n ect or.
Mea su r e th e resist an ce bet ween t h e Sen sor Gr ou n d cir cu it a n d a ll ot h er circu it s in
th e TCM C1 a n d C2 h a r ness con n ect or s.
Is t h e resista n ce below 5.0 ohm s on a n y of t h e circu it s?
All
Ye s → Repa ir t h e Sen sor Gr ou n d cir cu it for a sh or t t o ot h er circu it s.
Per for m N AG1 TRAN SMISSION VE RIF ICATION TE ST - VER 1.
No → Go To 7
118
TRANSMISSION - NAG1
TRAN S TEMP S EN S OR - P /N S WITCH CIRCU IT — Co n t i n u ed
