Symptom:
TR AN S TE MP S E N S OR S H ORTE D
Wh e n Mo n i to re d a n d S e t Co n d it i o n :
TR AN S TE MP S E N S OR S HOR TED
Wh en Mon it or ed: Alwa ys m on it or ed wit h syst em a ct ive
Set Con dit ion : Tem pera t ur e sen sor in pu t below a th resh old, failed t em per at u re sen sor,
sh or t t o gr oun d, TCM
POSSIBLE CAUSES
TE MP SE NSOR - P /N SWITCH CIRCUIT SH ORT TO GROUND
TE MP SE NSOR - P /N SWITCH CIRCUIT SH ORT TO OTH E R CIRCU ITS
TCM - P /N SWITCH CIRCUIT
TRANSMISSION TE MP ERATU RE SE NSOR
TCM - TRANS TE MP SE N SOR SH ORTE D
TRANSMISSION TE MP SENSOR - P/N SWITCH
TE S T ACTION AP PLICAB ILITY
1 NOTE: Low fluid level can be the cause of many transmission problems. If
the fluid level is low locate and repair the leak then check and adjust the
flui d lev el p er t h e s e r vi c e i n fo r m a ti o n .
NOTE: Always perform diagnostics with a fully charged battery to avoid
fa ls e s y m p t o m s .
Wit h t h e DRBIII#, r ea d t h e en gin e DTCs. Ch eck a n d r epa ir all en gin e DTCs pr ior to
per for m in g t r a n sm ission sympt om dia gnost ics.
Wit h th e DRBIII#, r ea d a n d recor d a ll Tra n sm ission DTCs.
NOTE: Ch e c k c o n n e c to rs - Cle a n /re pa i r a s n e c e s s a ry. P o o r p in to te rm in a l
connections can set DTCs.
Usin g t h e wir in g dia gr a m /schem a t ic a s a gu ide, in spect t he wir in g a n d con n ect or s.
Repa ir a s n ecessa r y.
Most DTCs set on st a r t up bu t som e m u st be set by dr iving th e veh icle su ch t h a t a ll
dia gnost ic m on itor s h a ve r u n .
Note: Verify flash level of transmission controller. Some problems are
corrected by software upgrades to the transmission controller.
NOTE: Ch e c k fo r a n y Te ch n ic a l S e rv ic e B u lle t in s th at m a y ap p ly.
Per for m t h is pr ocedu r e pr ior to Sym pt om dia gn osis.
All
Con t in u e
Go To 2
2 Att em pt to st a r t th e veh icle in Pa r k an d Neu t r a l.
Does t h e engin e st a r t in eit h er posit ion , P a r k or Neu t r a l?
All
Ye s → Go To 3
No → Go To 5
122
TRANSMISSION - NAG1
