TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off.
Discon n ect t he Rea r Door J a m b Swit ch con n ect or.
En su r e th e slidin g door (s) ar e closed or t h e swit ch es a r e discon n ect ed.
Obser ve th e cou rt esy la m ps.
Did t h e cou r t esy la m ps go off?
All
Ye s → Repla ce th e Rear Door J a m b Swit ch .
Per for m BODY VERIFICATION TE ST - VE R 1.
No → Go To 4
4 Tur n th e ign it ion off.
Discon n ect t he Secu r it y Syst em Modu le C1 conn ect or.
En su r e th e slidin g a n d r ea r door s a r e closed or t h e swit ch es a r e discon n ect ed.
Obser ve th e cou rt esy la m ps.
Did t h e cou r t esy la m ps go off?
All
Ye s → Repla ce th e Secu r ity Syst em Modu le in a ccor da nce wit h ser vice
in for m a t ion .
Per for m BODY VERIFICATION TE ST - VE R 1.
No → Repa ir t h e Rea r Cou r t esy La m ps Con t r ol cir cuit for a sh or t t o
gr ou n d.
Per for m BODY VERIFICATION TE ST - VE R 1.
230
VEH ICLE TH EFT /SECU RI TY
REAR OR SLIDING DOOR JAMB SWITCH CIRCUIT SHORT TO GROUND
—
Co n t in ued
