Symptom List:
AN TI-LOCK B RAKE MOD U LE IN TERN AL
CAB IN TE RN AL
Te s t N o t e : Al l s y m p t o m s l i s t e d a b o v e a r e d i a g n o s e d u s i n g t h e s a m e t e s t s .
Th e title fo r th e te s ts w ill be AN TI-LOCK B RAKE MOD U LE
IN TE RN AL.
Wh e n Mo n i to re d a n d S e t Co n d it i o n :
AN TI-LOCK B RAKE MOD ULE IN TERN AL
Wh en Mon it or ed: Ign it ion On - Con t inu ou sly.
Set Con dit ion : Wh en t h er e is a devia t ion fr om t h e expect ed r esu lt of a CAB in ter n a l self
check.
CAB IN TER N AL
Wh en Mon it or ed: Ign it ion On - Con t inu ou sly.
Set Con dit ion : Wh en t h er e is a devia t ion fr om t h e expect ed r esu lt of a CAB in ter n a l self
check.
POSSIBLE CAUSES
IN TE RMITTE NT CAB INTE RNAL DTC
DAMAGE D CAB/CAB HARN E SS CONNE CTOR
FUSE D OPTIONAL E QU IP ME NT RE LAY OUTP U T CIRCU IT OP EN
FUSE D B(+) CIRCUIT OP EN
GROU ND CI RCUI T OP E N
ANTI-LOCK BRAKE CONTROLLE R
TE S T ACTION AP PLICAB ILITY
1 Tur n th e ign it ion on .
Wit h th e DRBIII",readDTCs.
Wit h th e DRBIII",eraseDTCs.
Tur n th e ign it ion off.
Tur n th e ign it ion on .
Wit h th e DRBIII",readDTCs.
Does t h is DTC r eset ?
All
Ye s → Go To 2
No → Go To 6
10
BRAK ES (CAB)
