TE S T ACTION AP PLICAB ILITY
10 Tur n th e ign it ion off.
Discon n ect t he CAB ha r n ess con n ect or.
Discon n ect t he C1 Br a ke Swit ch a n d C2 Br a k e La m p Swit ch h a r n ess con n ect or s.
Mea su r e th e r esista n ce bet ween t h e Bra k e Swit ch Ou t pu t cir cu it a n d Br a ke La mp
Swit ch Ou t pu t cir cu it in th e C1 a n d C2 conn ect or s.
Is t h e resista n ce below 5.0 ohm s?
All
Ye s → Repa ir t h e Br a ke Swit ch Ou t pu t cir cu it for a sh or t t o t h e Br a k e
La m p Swit ch Out pu t cir cu it .
Per for m ABS VE RIF ICATION TE ST - VER 1.
No → Repla ce t h e Con t r oller Ant ilock Br a ke in a ccor da n ce wit h t h e
Ser vice In for m a t ion .
Per for m ABS VE RIF ICATION TE ST - VER 1.
20
BRAK ES (CAB)
BRAKE SWITCH CIRCUIT — Co nt in ued
To Next Page
