TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off.
Discon n ect t he La t era l Acceler a t ion Sen sor ha r n ess conn ect or.
Discon n ect t he CAB ha r n ess con n ect or.
Tur n th e ign it ion on .
Mea su r e th e volt a ge on all 4 of t h e La t er a l Acceler a t ion Sen sor sign a l cir cu it s.
Mea su r e th e volt a ge of th e La ter a l Acceler a t ion Sen sor gr ou n d cir cu it.
Th er e sh ou ld be no volt a ge pr esen t on an y of th e cir cuit s.
Mea su r e t h e resista n ce bet ween th e La t er a l Acceler a t ion su pply cir cu it an d a ll 4 of
th e La ter a l Acceler a t ion Sen sor sign a l cir cu it s.
Th e r esist a n ce bet ween th e cir cu it s sh ou ld be a bove 5.0 ohm s.
Wer e th er e an y pr oblem s fou n d?
All
Ye s → Repa ir t h e sh or t ed La t er a l Acceler a t ion Sen sor circu it (s).
No → Go To 4
4 Tur n th e ign it ion off.
Discon n ect t he La t era l Acceler a t ion Sen sor ha r n ess conn ect or.
Discon n ect t he CAB ha r n ess con n ect or.
Mea su r e t h e resist a n ce bet ween t h e La t er a l Accelera t ion Sen sor gr ou n d an d t he 4
La t er a l Acceler a t ion Sen sor sign a l circu it s.
Mea su r e th e resist a n ce bet ween gr ou n d an d t h e 4 La t er a l Acceler a t ion Sen sor sign a l
cir cu it s.
Mea su r e th e r esist a n ce bet ween gr ou n d a n d t h e La t er a l Acceler a t ion Sen sor su pply
cir cu it .
Is t h e resista n ce below 5.0 ohm s for a n y of t h e circu it s?
All
Ye s → Repa ir t h e La ter a l Acceler a t ion Sen sor cir cu it (s) for a sh or t t o
gr ou n d.
No → Go To 5
5 Tur n th e ign it ion off.
Discon n ect t he La t era l Acceler a t ion Sen sor ha r n ess conn ect or.
Discon n ect t he CAB ha r n ess con n ect or.
Mea su r e th e resista n ce of t h e La t er a l Acceler a t ion Sen sor su pply cir cu it.
Mea su r e th e resista n ce of t h e La t er a l Acceler a t ion Sen sor gr ou n d cir cu it .
Mea su r e th e resista n ce of t h e 4 La t er a l Acceler a t ion Sen sor sign al cir cu its.
Is t h e resista n ce a bove 5.0 ohm s for a n y of t h e circu it s?
All
Ye s → Repa ir t h e La t er a l Acceler a t ion Sen sor cir cu it (s) for a n open
No → Go To 6
6 Tur n th e ign it ion off.
Discon n ect t he La t era l Acceler a t ion Sen sor ha r n ess conn ect or.
In spect th e ha r n ess a n d con n ect or s r ela t ed to t h is cir cu it. If a n y pr oblem s a r e fou n d,
repa ir a s n ecessa r y.
If n o pr oblem s ar e fou n d, repla ce t h e La t er a l Accelera t ion Sen sor i n accor da n ce wit h
th e Ser vice In form a t ion .
Wit h th e DRBIII", clea r DTCs.
Wit h th e DRBIII", per for m t h e roa d t est pr ocedu r e.
Wit h th e DRBIII",readDTCs.
Does t h is DTC r eset ?
All
Ye s → Repla ce th e CAB in accor da n ce wit h t he Ser vice In for ma t ion .
No → Test Com plet e.
30
BRAK ES (CAB)
DRIVE TEST ERROR — Co n t in ued
