Symptom List:
LATER AL ACCELE RATION S E N S OR CIR CU IT
LATER AL ACCELE RATION S E N S OR IMPLAU S IB LE
Te s t N o t e : Al l s y m p t o m s l i s t e d a b o v e a r e d i a g n o s e d u s i n g t h e s a m e t e s t s .
Th e t it le fo r t h e tes t s will b e LATER AL ACCE LER ATION
SENSOR CIRCUIT.
POSSIBLE CAUSES
LATE RAL ACCE LERATION SE NSOR CIRCU IT INTE RMITTENT DTC
STEE RING COMPONENT INSP ECTION
LATE RAL ACCE LERATION SE NSOR CIRCU IT SH ORT TO VOLTAGE
LATE RAL ACCE LERATION SE NSOR CIRCU IT SH ORT TO GROUND
LATE RAL ACCE LERATION SE NSOR CIRCU IT OP EN
LATE RAL ACCE LERATION SE NSOR
ANTI-LOCK BRAKE CONTROLLE R
TE S T ACTION AP PLICAB ILITY
1 Tur n th e ign it ion off.
Tur n th e ign it ion on .
Wit h th e DRBIII", r ea d DTCs. Recor d DTC in for m a t ion .
NOTE: If a system undervoltage or overvoltage DTC is set along with this
DTC, diagnose the system voltage DTC first.
NOTE: Electromagnetic (radio) interference can cause an intermittent
system malfunction by interrupting communication between the sensor
and the CAB.
Wit h th e DRBIII",eraseDTCs.
Roa d t est th e veh icle a nd per for m sever a l br a king ma n eu ver s.
Wit h th e DRBIII", per for m t h e roa d t est pr ocedu r e.
Wit h th e DRBIII",readDTCs.
Does t h is DTC r eset ?
All
Ye s → Go To 2
No → Go To 7
2 NOTE: When the vehicle is in a turn, the ESP compares the Steering Angle
Sensor value and the speed of the inner and outer wheels to determine if the
values are plausible.
In spect t h e fr on t en d a n d st eer in g com pon en ts for da ma ge or m isa lign m en t.
In spect t h e La t er a l Acceler a t ion Sen sor for corr ect m ou n t in g a n d in sta lla t ion .
In spect t h e t ir es an d wh eels to ma k e su r e t h a t t h ey ar e t h e cor r ect size. All t ir es m u st
be t h e sa m e s ize.
Wer e an y pr oblem s fou n d?
All
Ye s → Repa ir or r epla ce com ponen t s as n ecessa r y in a ccor da n ce wit h th e
Ser vice In for m a t ion .
No → Go To 3
36
BRAK ES (CAB)
