Symptom:
STEERING ANGLE SENSOR IMPLAUSIBLE CAN SIGNAL
POSSIBLE CAUSES
STEE RING ANGLE SE NSOR INTE RMITTE NT DTC
STEE RING ANGLE SE NSOR CAN CIRCUIT OP E N
STEE RING ANGLE SE NSOR
ANTI-LOCK BRAKE CONTROLLE R
TE S T ACTION AP PLICAB ILITY
1 NOTE: If a system undervoltage or overvoltage DTC is set along with this
DTC, diagnose the system voltage DTC first.
NOTE: Electromagnetic (radio) interference can cause an intermittent
system malfunction by interrupting communication between the sensor
and the CAB.
NOTE: The Steering Angle Sensor is very sensitive to changes due to
alignment problems. The sensor must be recalculated using the DRBIII" if
alignment has been changed by more than 5 degrees.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseDTCs.
Test drive th e veh icle.
Using the DRBIII", per for m th e roa d t est pr ocedu r e.
Wit h th e DRBIII",readDTCs.
NOTE: If the ESP lamp remains illuminated after the test has completed, a
fa u l t c o d e w i ll b e s et i n d i c a ti n g t h e c a u s e o f t h e fa i lu r e .
Does t h is DTC r eset ?
All
Ye s → Go To 2
No → Go To 4
2 Tur n th e ign it ion off.
Discon n ect t he St eer in g An gle Sen sor ha r n ess con n ect or.
Discon n ect t he CAB ha r n ess con n ect or.
Mea su r e th e resista n ce of t h e St eer in g Angle Sen sor CAN (+) circu it .
Mea su r e th e resista n ce of t h e St eer in g Angle Sen sor CAN (-) cir cu it .
Is t h e resista n ce a bove 5.0 ohm s for eit h er cir cuit ?
All
Ye s → Repa ir t h e St eer in g Angle Sen sor CAN cir cu it for an open .
No → Go To 3
68
BRAK ES (CAB)
