Ve r i f i c a t i o n Te s t s
ABS VERI FIC ATI ON T E ST - VE R 1 APP L IC ABI LI TY
1. Tu r n th e ign it ion off.
2. Con n ect a ll pr eviou sly disconn ect ed com pon en t s a n d con n ect or s.
3. E n su r e all a ccessor ies a re t u r ned off an d t h e ba t t er y is fu lly ch a r ged.
4. E n su r e th a t t he Ign it ion is on , a n d wit h t h e DRBIII, er a se all Dia gn ost ic Tr ou ble Codes fr om
ALL m odu les. St a r t t h e en gine an d allow it to ru n for 2 minu t es an d fully oper a t e t h e syst em
th a t wa s m a lfu n ct ion in g.
5. Tur n t h e ignit ion off a n d wa it 5 secon ds. Tu rn th e ign it ion on a n d u sin g th e DRBIII, r ea d
DTC’s from ALL m odu les.
6. If a n y Dia gnost ic Tr ou ble Codes a r e pr esen t , r et u rn t o Sym pt om list an d t r ou blesh oot new
or recu r r in g sym pt om .
7. N OTE: If th e CAB /HCU w as re p la c e d , e n s u re t h e CAB h a s be e n in it ia li ze d
8. N OTE: If th e S KREEM or ECM w as re pla ce d, re fer to th e s ervice in form atio n for
proper programming procedures.
9. NOTE: Fo r S e n s o r Ci rc u it/S ig n al a n d P u m p Mo t o r fa u lts , th e CAB m u s t se n s e a ll 4
w h e e ls at 12 k m /h (8 m p h ) be fo re it w ill e x ti n g u is h th e AB S In dic a t o r .
10. If th er e ar e n o DTC’s presen t aft er tu r n in g ign it ion on, roa d t est th e vehicle for a t lea st 5
min u tes. P er for m sever a l a n t ilock br a king st ops.
11. C A UTI ON : En su re brakin g c apability is ava ilable be f o re road te stin g.
12. Aga in , wit h t he DRBIII" r ea d DTC’s. If an y DTC’s a r e pr esen t, r et u r n to Sym pt om list .
13. If t h er e a r e n o Diagn ost ic Tr ou ble Codes (DTC’s) pr esen t , a n d t h e cu st om er ’s con cern ca n
no lon ger be du plica t ed, th e r epa ir is com plet e.
Are a n y DTC’s presen t or is t h e origin a l con cer n st ill pr esen t ?
All
Ye s → Repa ir is n ot complet e, r efer to a ppropr ia t e sym pt om .
No → Repa ir is com plete.
79
