TE S T ACTION AP PLICAB ILITY
3 NOTE: Inspect all air intake and turbocharger related tubes for damage,
re stric tio n o r p oor co nn ectio n. Any of th ese c on dition s c an c au se a th is DTC
to set.
Tur n th e ign it ion off.
In spect a ll a ir in t a ke a nd t u r boch a r ger r ela t ed t ubes a n d con n ect ion s.
Wer e an y pr oblem s fou n d?
All
Ye s → Repa ir or repla ce as n ecessa r y.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 4
4 Wit h t h e DRBIII", rea d t h e a ct ive a n d st or ed DTCs for t h e Tr a n sm ission Con t rol
Modu le.
NOTE: Due to capabilities of certain controllers that use the CAN Bus, not
all modules report CAN Bus DTCs.
Is t h e TCM r epor t in g a ct ive or st or ed CAN Bu s com m u n ica t ion DTCs r elat ed to th e
Sh ift er Modu le?
All
Ye s → Refer t o sym pt om list to dia gn ose CAN Bu s DTC in t h e TCM.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 5
5 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he Sh ift er Module ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or.
NOTE: Ch e c k c o n n e c to rs - Cle an /re pa i r a s n e c e ss a ry.
Mea su r e th e r esist a n ce of bot h th e CAN C Bu s (+) cir cu it a n d th e CAN C Bu s (-)
cir cu it bet ween t he Sh ift er Module ha r n ess con n ect or an d E CM ha r n ess con n ect or.
Is t h e resista n ce below 10.0 ohm s for ea ch mea su rem en t ?
All
Ye s → Go To 6
No → Repa ir t h e CAN C Bu s (+) a nd/or CAN C Bu s (-) cir cu it for an
open .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
6 Tur n th e ign it ion off.
Discon n ect t he In t a ke P r essu r e Sen sor ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e th e resista n ce of t h e In ta k e Pr essu r e Sen sor Sign a l cir cu it .
Is t h e resista n ce below 10.0 ohm s?
All
Ye s → Go To 7
No → Repa ir t h e In ta k e Pr essu r e Sen sor Sign a l circu it for h igh r esis-
ta n ce.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
7 Tur n th e ign it ion off.
Discon n ect t he In t a ke P r essu r e Sen sor ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e th e resista n ce of t h e Sensor Gr ou n d circu it .
Is t h e resista n ce below 10.0 ohm s?
All
Ye s → Go To 8
No → Repa ir th e In t ak e P r essu r e Sen sor Gr ou n d cir cuit for high resis-
ta n ce.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
26
DRI V EABI LI T Y - DI ESEL
P 0105-IN TAKE P RES S URE S ENS OR CAN MESS AGE ERROR — Co n t in ued
