Dodge Sprinter 2006 - Page 450

TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off.
Discon n ect t he In t a ke P r essu r e Sen sor ha r n ess con n ect or.
Tur n th e ign it ion on .
Con n ect a ju m per wir e bet ween th e In ta k e P r essu r e Sen sor Sign a l cir cu it an d t h e
In t a ke Pr essu r e Sen sor 5-Volt Supply cir cu it .
Wit h th e DRB, r ea d t h e In t ak e Pr essu r e Sen sor volt a ge.
Is t h e In t a ke Pr essu r e Sen sor volta ge above 4.5 volt s?
All
Ye s → Repla ce th e In t a ke P ressur e Sen sor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 4
4 Tur n th e ign it ion off.
Discon n ect t he In t a ke P r essu r e Sen sor ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t h e resist an ce bet ween gr ou n d a n d th e In t a ke Pr essu r e Sen sor Sign a l
cir cu it .
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 5
No → Repa ir t h e In t a ke Pr essu r e Sen sor Sign a l cir cu it for a sh ort t o
gr ou n d.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
5 Tur n th e ign it ion off.
Discon n ect t he In t a ke P r essu r e Sen sor ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t h e r esist a n ce bet ween t h e In ta k e P r essu r e Sensor Sign a l cir cu it a nd
Sen sor Gr ou n d cir cu it .
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 6
No → Repa ir th e In t a ke Pr essu r e Sen sor Sign a l cir cu it for a sh or t to t h e
Sen sor Gr ou n d cir cu it .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
6 Tur n th e ign it ion off.
Discon n ect t he In t a ke P r essu r e Sen sor ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e th e resista n ce of t h e In ta k e Pr essu r e Sen sor Sign a l cir cu it .
Is t h e resista n ce below 10.0 ohm s?
All
Ye s → Go To 7
No → Repa ir th e In t a ke P r essu re Sen sor Signa l cir cu it for a n open .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
7 If t h er e ar e no possible cau ses r em a in ing, view repa ir. All
Repa ir
Repla ce a n d pr ogr a m th e En gin e Con t rol Module in a ccor da nce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
32
DRI V EABI LI T Y - DI ESEL
P 0105-IN TAKE P RESS U RE SENS OR S IGNAL VOLTAGE TOO LOW —
Co n t in ued
